Laboratory Board (DSP 6713)




The TMS320C6713 Laboratory Board (DSP 6713) (DSK) is a low-cost development platform designed to speed the development of high precision applications based on TI's TMS320C6000 floating point DSP generation. The Laboratory Board (DSP 6713) uses USB communications for true plug-and-play functionality. Both experienced and novice designers can get started immediately with innovative product designs with the DSK's full featured code composer studio IDE and eXpres DSP software (optional) which includes DSP/BIOS and reference frameworks. All users will benefit from the express DSP for dummies textbook featured for the first time in this DSK.

The Laboratory Board (DSP 6713) includes
  • 3.5mm audio jacks for line in and line out
  • 2M Flash and 16MB SDRAM
  • HPI/GPIO port connector
  • MC Bspi Port connector
  • On board standard IEEE Jtag interface via USB
  • +5 V universal power supply
  • Analog interface for data conversion (AIC)
  • Experiments workbook
  • Code composer studio IDE

JTAG Emulator Features
  • USB2.0 full use of standard computer interface connector
  • Completely plug-and-play
  • Transmission speed of up to 480 Mbps
  • Compatible with USB 1.1 agreement
  • 14 Pin Jtag simulation interface
  • Support windows 98 / NT/2000/XP operating system
  • Support TI CCS V2.0, V2.1, V2.2, support CCS3.1, CCS3.2, CCS3.3 central integrated development
  • Habitat to support c language and assembly language
  • Off-target system resources to support the number of DSP debugging simulation at the same time
