SUPERPRO Programmer (610P)




Our company specializes in exporting and supplying of SUPERPRO Programmer (610P). A USB interfaced ultra high device programmer, 610P Support devices with Vcc from 1.2V to 5V.

Features

    • Support devices with Vcc from 1.2V to 5V.
    • Extremely fast speed.
    • Built with 48 universal pin-drivers.
    • PC hosted mode and stand-alone mode. Under PC hosted mode the programmer is controlled by a PC via USB2.0 (high speed) to program a chip.
    • ISP/ICP programming capability available via ISP/ICP adaptor.
    • Only IC manufacturer approved programming algorithms are used for high reliability. (+5%~-5%) and (10%~-10%) Vcc verification enhances programming reliability.
    • Advanced and powerful functions.



    • Production mode start chip operation at the moment the chip is inserted in the socket properly.
    • Project function simplifies processes such as device selection, file loading, device configuration setting, program option, and batch file setting into one touch step
    • Password can be set for project files and production volume control
    • Batch command combines device operations like program, verify, security into a single command at any sequence.
    • Serial numbers generators are available as standard or customer-specific functions.
    • Log file is useful for quality tracking
  • Over-current and over-voltage protection for safety of the chip and programmer hardware
  • WINDOWS XP/Vista compatibility


Device Updates

  • XELTEK updates software and device algorithm regularly.
  • View the latestDevice List
  • Download the current software version free of charge .
  • Updates are available by mail at a nominal charge.
  • XELTEK also adds devices upon customers request at its
    option.


Warranty Support : Programmer is warranted to be free of manufacturing or workmanship defects for one year from the date of purchase.

Hardware & Electrical Specifications

    • Supported devices : EPROM, Paged EPROM, Parallel and Serial EEPROM, BPROM, NVRAM, SPLD, CPLD, EPLD,
      Firmware HUB, Microcontroller, MCU, Standard Logic. .
    • Packages supported : DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, CSP, SCSP
    • PC interface : USB2.0
    • Stand-alone Feature : None.
    • Electrical spec. of the AC adapter : AC input 90V to 250V, 50/60Hz, DC output 12V/2A; power : 15W
    • Mechanical parameter : Size - 178*130*40 mm
    • Packing Box :



    • Size : 320*300*85 mm
    • Weight : 1.8 Kg


Accessories

  • Main unit with a DIP48 adaptor, AC adaptor, USB2.0 cable, software CD (include: install software, user manual), register card
  • Optional Accessories : adaptor in varies packages.
