FPGA Trainer Kit (ET Spartan 50-200K)




We are a well-known Exporter and Supplier of FPGA Trainer Kit (ET Spartan 50-200K). It uses Xilinx Spartan XC2S50/XC2S100/XC2S200 FPGA with up to 50/100/200K system gates, and up to 200MHz clock speed.

Features
  • It uses Xilinx Spartan XC2S50/XC2S100/XC2S200 FPGA with up to 50/100/200K system gates, and up to 200MHz clock speed.
  • It communicates with computer through standard Webpack
  • User can develop the circuit/ schematic using Xilinx standard Foundation Series Software and any development tool for VLSI design available in the world.
  • It has various on-board interfaces :
    • 16x2 LCD module
    • Six Seven Segment Displays
    • Stepper Motor Controller Interface
    • 8x8 LED Matrix Display
    • EWSN Status LED's 12 Nos.
    • ADC/DAC Interface
    • RS-232 interface
    • Parallel JTAG interface
  • Four Data Switches
  • Switch Array
  • AT24C16 Serial EEPROM
  • 4x4 Keyboard
  • Power Indicator LED
  • It has on board 89C51RD2 for development and processing f 51 family softwares.
  • On board microcontroller with 64K flash, 1K RAM ISP with required software.
  • It has I/O counter interface to enable it to connect various demo modules. This helps in man to machine interface.
  • Has a general purpose areas on board to enable it to incorporate additional circuit

Package Contents
  • VPL-SPARTAN Board
  • Set of cables flat and serial
  • Application CD ROM
  • User's Manual : detailed information on components and usage
  • Data sheet of major components
  • List of experiments for FPGA as listed
  • On board facility for variable clock generation
