Trainer Kit (BT)




We are considered a dependable Exporter and Supplier of . Trainer Kit (BT) is a Bluetooth Serial Development Board. It works in a wireless range of over 100M (130 ft). Trainer Kit (BT) supports interface with RS-232 system.

Specifications
  • Frequency : 2400~2483.5MHz
  • Modulation : FHSS/GFSK 1Mbps, 1600hop/s
  • Data Transmission Speed : 723.2k/57.6kbps (asymmetrical, max.) 433.9kbps (symmetrical, max.)
  • Max Transmission Power : 20dBm (BluetoothTM TX power class 1)
  • Receiving Sensitivity : -80dBm~-20dBm
  • Coverage : 0.5m~100m (Varies depending on use environment)
  • Operating System : Windows 98SE, Windows ME, Windows 2000, Windows XP
  • Current Consumption : 80mA standard

Experiments
  • Message on LCD
  • Transfer of data from trainer to PC
  • ADC1 value display on LCD
  • Running of stepper motor
  • Read/Write EEPROM at 0 location and display on LCD
  • RTC display on LCD
  • Relay ON/OFF
  • Buzzer ON/OFF

Package Contents
  • Blue Tooth Trainer Kit
  • Blue Tooth Dongle
  • ASCII Keyboard
  • RS-232 Serial Cable
  • Technical User Manual

Note : Specifications can be changed and added without notice in our constant efforts for improvement.
